Príruba PP-V na tupo zváranie
- Ďalšie informácie
Ďalšie informácie
| d(mm) | 355, 400, 16, 20, 25, 32, 40, 50, 63, 75, 90, 110, 125, 140, 160, 180, 200, 225, 250, 280, 315 |
|---|---|
| DN | 10, 100, 125, 15, 150, 20, 200, 225, 25, 250, 300, 32, 350, 40, 400, 50, 65, 80 |
| PN(bar) | 10, 16 |
| Kat. číslo | d(mm) | DN | PN(bar) | Množstvo | |
|---|---|---|---|---|---|
| 727 700 406, | 20 | 15 | 16 | ||
| 727 700 407, | 25 | 20 | 16 | ||
| 727 700 408, | 32 | 25 | 16 | ||
| 727 700 409, | 40 | 32 | 16 | ||
| 727 700 410, | 50 | 40 | 16 | ||
| 727 700 411, | 63 | 50 | 16 | ||
| 727 700 412, | 75 | 65 | 16 | ||
| 727 700 513 | 90 | 80 | 16 | ||
| 727 700 514 | 110 | 100 | 16 | ||
| 727 700 516 | 140 | 125 | 16 | ||
| 727 700 517 | 160 | 150 | 16 | ||
| 727 700 518 | 180 | 150 | 16 | ||
| 727 700 519 | 200 | 200 | 16 | ||
| 727 700 520 | 225 | 200 | 16 | ||
| 727 700 521 | 250 | 250 | 10 | ||
| 727 700 522 | 280 | 250 | 10 | ||
| 727 700 523 | 315 | 300 | 10 | ||
| 727 700 524 | 355 | 350 | 10 | ||
| 727 700 525 | 400 | 400 | 10 |
